CipherLab 9700 Reference Manual

166
9700 Mobile Computer (CE) Reference Manual
5.2.2. LAUNCH SIGNATURE UTILITY
To launch Signature utility:
1) Tap Start | Programs | Signature
.
Signature utility opens showing a toolbar along the top and a signing area within its
window.
TOOLBAR & SIGNING AREA
Toolbar features a few icons to launch actions from the utility.
Toolbar icon
Description
Creates a new file.
Loads a signature image.
Saves the affixed signature to an image file (BMP, JPG or Locus format).
Clears signing area.
Opens preferences settings.
Views utility info including developer and software version.
Toolbar
Signing area

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
