CipherLab 9700 Reference Manual

227
The tables below list the symbology settings for the 2D imager (SE4500DL).
SYMBOLOGY SETTINGS
1D SYMBOLOGIES
Symbology Description Default
CODABAR
CodaBar
Codabar Checkbox to enable Codabar decoding. Enable
Length option Sets the length of the Codabar symbols to decode.
 One Fixed length (Length 1)
 Two Fixed lengths (Length 1>Length 2)
 Max / Min Length (range: 0-55; Length 1<Length 2)
 Any Length
Max / Min
Length
(4-55)
CLSI When applied, the CLSI editing strips the start/stop
characters and inserts a space after the first, fifth, and tenth
characters of a 14-character Codabar barcode.
 The 14-character barcode length does not include
start/stop characters.
Disable
NOTIS Sets whether to include start/stop characters in the
transmitted data.
 NOTIS Editing is to strip the start/stop characters, i.e. to
disable "Transmit Start/Stop Characters".
Disable
CODE 11
Code 11
Code 11 Checkbox to enable Code 11 decoding. Enable
Check Digit Option Sets whether to verify check digits according to the selected
option. If the check digits are incorrect, the barcode will not
be accepted.
 Disable
 One Check Digit
 Two Check Digits
Disable
Transmit Check Digit Selects whether to include check digits in the transmitted
data.
 Check Digit Option” must be enabled.
Disable
Length option Sets the length of the Code 11 symbols to decode.
 One Fixed length (Length 1)
 Two Fixed lengths (Length 1>Length 2)
 Max / Min Length (range: 0-55; Length 1<Length 2)
 Any Length
Max / Min
Length
(4-55)
Appendix IV
2D IMAGER (SE4500DL)

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
