CipherLab 9700 Reference Manual

207
9700 Series Mobile Computer supports the following reader types. Reader availability
depends on the hardware integrated on the mobile computer.
Scan Engine
ID
1D Laser SE955
1D Extra Long Range Laser SE1524
SE4500 2D 2D Imager
SE4500 + PL4507
2D Extra Long Range 2D Imager EX25
Reader combination allowed is either 1D or 2D. When you hit a physical scan key, the
mobile computer reads a printed barcode which is in position.
Note: 1D and 2D scan engines don’t coexist on the mobile computer because they are both
barcode readers and the mobile computer allows only one barcode reader on board.
IN THIS CHAPTER
Symbologies Supported...................................................208
Appendix I
SCAN ENGINE SETTINGS

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
