CipherLab 9700 Reference Manual

98
9700 Mobile Computer (CE) Reference Manual
CREATE WI-FI PROFILE
To create a Wi-Fi Profile:
1) Open SCU as described in
Launch SCU.
2) Tap the Configuration tab to show the Configuration tabbed page.
3) Tap Scan to view a list of access points that are broadcasting their SSIDs. You may sort
the list by tapping the column headers.
Tap Refresh to update the list of available access points.
Item
Description
SSID Service Set Identifier (SSID)
RSSI Received Signal Strength Indication (RSSI)
Secure Indicates whether data encryption is enabled: true or false
4) Tap twice on any of the access points to create a new profile for it. A prompt shows
confirming whether to create a profile with the identified SSID, encryption and EAP type.
Tap Yes to continue.

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
