113
Chapte
r
4 Radios
USE PING TOOLS
To perform ping tests, select Ping Tools in the drop-down bar.
Item
Description
Destination Enter the address to ping.
Ping Payload The amount of data to be transmitted on a ping.
Value: 32, 64, 128, 256, 512, 1024
Default: 32 (bytes)
Ping Delay The amount of time that elapses between successive ping requests.
Value: 0~7200000
Default: 1000 (milliseconds)
Timeout ms The amount of time that elapses without a response before ping request is
considered a failure.
Value: 0~30000
Default: 5000 (milliseconds)
Start Ping Enter the address to ping to in the Destination field and tap Start Ping. A
continuous ping will begin until the following happens: Stop Ping is tapped, the,
the application is exited, or the radio is removed. Activity status will be logged in
the output box below.
Select Ping Tools to diagnose the
connection
Device IP address
AP Name

Table of Contents

Other manuals for CipherLab 9700

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the CipherLab 9700 and is the answer not in the manual?

CipherLab 9700 Specifications

General IconGeneral
Battery voltage3.7 V
Battery capacity3600 mAh
Battery life (max)13 h
Display diagonal3.5 \
Touchscreen typeResistive
Display resolution640 x 480 pixels
Flash memory4 GB
Internal memory0.512 GB
Internal memory typeDDR
Compatible memory cardsSD, SDHC
Processor familyOMAP 3730
Processor frequency1 GHz
Processor manufacturerTexas Instruments
GPS (satellite)-
Operating system installedWindows Embedded CE 6.0 R3
Data networkNot supported
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version2.1+EDR
Security algorithmsWEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in cameraNo
Storage temperature (T-T)-30 - 70 °C
Operating temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)10 - 90 %
CertificationFCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product colorBlack, Yellow
Keyboard layoutAlphanumeric
International Protection (IP) codeIP65
Weight and Dimensions IconWeight and Dimensions
Depth47 mm
Width87 mm
Height214 mm
Weight447 g
