CipherLab 9700 Reference Manual

152
9700 Mobile Computer (CE) Reference Manual
DISABLE/ENABLE KEY FUNCTION
The last column in the Device Setting list gives an overview of key status. Users can disable
or enable a key by giving a single tap on this column. By disabling keys, keys are “locked”
as no actual function will take place when they are pressed.
Enabled items will display as
while disabled items will appear as .
Tap the “Enabled” column to enable or disable
the indicated function.
Once keys are disabled, the icon changes and
the function for that key will appear as
“None”.
Note:
(1) To access the settings page for a key, its status needs to be set as “Enabled”.
(2) When a key is disabled and then enabled, its function will return to default settings.

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
