225
Appendix III Lase
(SE1524)
UPC-E1
UPC-E1 Checkbox to enable UPC-E1 decoding. Disable
Preamble Decide whether to include the UPC-A/UPC-E/UPC-E1
preamble System Character (and Country Code) in the data
being transmitted.
No transmit: transmits none of the above
Transmit System Character: transmits system number
only
Transmit Sys. Character and Country Code: transmits
system number and country code
Transmit
System
Character
Convert to UPC-A The UPC-E1 barcode will be expanded into UPC-A format,
and the next process will follow the settings configured for
UPC-A.
Disable
Transmit Check Digit Decide whether to include the UPC-E1
check digit (the last
character in the barcode) in the data being transmitted.
Enable
General Preference
Support Coupon Code Reads UPC-A barcodes starting with “5”, EAN-13 barcodes
starting with “99”, and UPC-A/EAN-128 Coupon Codes.
UPC-A, EAN-13, and GS1-128 must be enabled first!
Use “Addon Redundancy” to control auto-discrimination
of the GS1-128 (right half) of a coupon code.
Disable
EAN Addon Option Decide whether to decode EAN-8, EAN-13
with addons
(including Addon 2 and 5).
Ignore Addon
Decode only with addons
Auto-discriminate
Ignore Addon
EAN Addon Redundancy
When “Auto-discriminate”
is applied, decide the number of
times of supplementary decoding the same barcode to count
as a valid read. Configurable between 2 and 30.
10
UPC Addon Option Decide whether to decode UPC-E0, UPC-E1, UPC-A with
addons (including Addon 2 and 5).
Ignore Addon
Decode only with addons
Auto-discriminate
Ignore Addon
UPC Addon Redundancy
When “Auto-discriminate”
is applied, decide the number of
times of supplementary decoding the same barcode to count
as a valid read. Configurable between 2 and 30.
10
