229
Appendix IV
2D Image
(SE4500DL)
Concatenation Sets whether to enable decoding ISBT-128 by performing
concatenation of ISBT data
Disable: Does not perform concatenation
Enable: Performs concatenation on all ISBT-128
barcodes.
Auto-discriminate: Auto-discriminates between the
ISBT-128 barcodes which require concatenation and
those which do not need concatenation.
Disable
Redundancy Sets redundancy between 2-20. 10
CODE 2 OF 5
Chinese 25
Enable Chinese 25 Checkbox to enable Chinese 25 decoding. Enable
Discrete 25
Discrete 25 Checkbox to enable Discrete 25 decoding. Enable
Length option Sets the length of the Code 39 symbols to decode.
One Fixed length (Length 1)
Two Fixed lengths (Length 1>Length 2)
Max / Min Length (range: 0-55; Length 1<Length 2)
Any Length
Max / Min
Length
(4-55)
Interleaved 25
Interleaved 25 Checkbox to enable Interleaved 2 of 5 decoding. Enable
Length option Sets the length of the Code 39 symbols to decode.
One Fixed length (Length 1)
Two Fixed lengths (Length 1>Length 2)
Max / Min Length (range: 0-55; Length 1<Length 2)
Any Length
Max / Min
Length
(4-55)
Verify Check Digit Decide whether to verify the check digit. If desired, select
one of the algorithms below. If the check digit is incorrect,
the barcode will not be accepted.
Disable
USS Check Digit
OPCC Check Digit
Disable
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Disable
Convert To EAN-13 Convert a 14-character Interleaved 25 barcode into EAN-13
if the following requirements are met:
The barcode must have a leading 0 and a valid EAN-13 check
digit.
Disable
Matrix 25
Matrix 25 Checkbox to enable Matrix 2 of 5 decoding. Enable
Length option Sets the length of the Code 39 symbols to decode.
One Fixed length (Length 1)
Two Fixed lengths (Length 1>Length 2)
Max / Min Length (range: 0-55; Length 1<Length 2)
Any Length
Max / Min
Length
(4-55)
Redundancy Sets read redundancy Disable
