CipherLab 9700 Reference Manual

246
9700 Mobile Computer (CE) Reference Manual
Right Right Right Highlight Right End
Enter Enter Enter Enter Enter
Backspace Backspace Backspace Backspace
Keypad
Lock
Esc Esc Esc Esc Esc
. . Shift Shift N/A
Space Space Space Space Windows
Ctrl Ctrl Ctrl Ctrl Alt
Green F14 F14 F14 F14
Red F15 F15 F15 F15
F1 F1 F1 Shift+F1 F5
F2 F2 F2 Shift+F2 F6
F3 F3 F3 Shift+F3 F7
F4 F4 F4 Shift+F4 F8
Note: Although keys 0-9 allow up to four presses to input different values, the function of
Ctrl and Alt can only be delivered to the value entered at the first press of each key.
For instance, the keypad can deliver the functions Ctrl+a and Alt+a, but not Ctrl+c
and Alt+c, since the letter “c” will require three presses of the number key “2”.

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
