CipherLab 9700 Reference Manual

16
9700 Mobile Computer (CE) Reference Manual
BATTERY STATUS ICONS
The OS features a couple of icons that deliver main battery status. These icons can be found
on the taskbar, which is settled at the bottom of every screen.
Battery level is illustrated by the following icons :
Icon
Battery Status
Main battery level is 91%~100%.
Main battery level is 71%~90%.
Main battery level is 51%~70%.
Main battery level is 21%~50%.
Main battery level is 11%~20%.
Main battery level is 1%~10%. Charge or replace main battery immediately!
Main battery is being charged from external power.
Mobile computer is connected to external power, but main battery level is
full and does not need charging.
Batter
y
char
g
in
g
icon

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
