22
9700 Mobile Computer (CE) Reference Manual
ALPHANUMERIC KEYPAD (53-KEY)
The 53-key alphanumeric keypad features not only letter
keys A-Z and number keys 0-9, but also many other keys for
extensive application when connected to a remote server.
Also included are an Esc key, Ctrl key, Backspace key, Shift
key, Enter key, period key (.) and comma key (,). Unlike the
other two keypads, the power key is located near the upper
right corner of the keypad.
As for modifier keys, the alphanumeric keypad features a
blue Alpha key
and Shift key . The Alpha key
combined with other keys on the keypad can enter a variety
of symbols, or adjust volume and touchscreen backlight. It
can also be used to trigger the Alt key, function keys F1-F10,
and enter other text editing keys (tab leftward and
rightward). As for the Shift key, it allows entering of Shift+1,
2, 3….10. In addition, it locks the keypad when used with
the Backspace key.
BASIC KEYS
These are a set of keys kept at the top of the keypad throughout all three keypad types.
Figure 8: Basic keys
Basic keys deliver the following functions:
Key
Description
SCAN KEY
Press the scan key to read a barcode in place.
ARROW KEYS
The arrow keys are circled around the center scan key. These can be used
to move the cursor up, down, left or right during text input, or move
between items in certain applications.
SEND/END KEY
By default, these two keys input the functions F14 and F15. You may also
define their new key functions using CipherLab’s Button Assignment.
