Chapter 11 Using the SD Flash Memory Module
Accessing the SD Card
Supported SD Cards
Table 11-1 lists the SD cards that can be used with the router.
Accessing the SD Card
The SD card and SD card LED are accessed from the router exterior, though the router SD card port,
shown in Figure 11-1.
Caution Do not remove the SD card from the router; removing the SD card will cause the router to stop operating.
The topics in this section include:
• Accessing the SD Card on a Router with a Mounting Bracket, page 11-2
Accessing the SD Card on a Router with a Mounting Bracket
When the Cisco mounting bracket is attached to the router, the bracket blocks access to the SD card port
slot on the router exterior. To access the SD card slot without removing the router from the bracket or
any mounting installation that uses the bracket, refer to the instructions in the “Mounting the Router”
section on page 5-1.
Table 11-1 Supported SD Flash Modules
Size
1-GB flash memory module
