Chapter 12 Installing Battery Backup Units
Preparing to Install the BBU
Figure 12-3 Rear of Battery Backup Unit
Item Description
1 Battery-to-battery connector, male. The BBU features two battery-to-battery
connectors: one male and one female, which are used to connect batteries together
when two or more batteries are installed in one router.
2 Captive screws (6)
