Cisco 1240 Connected Grid Router Hardware Installation Guide

OL-26223-04

Chapter 12 Installing Battery Backup Units

Installing a BBU in the Router

Figure 12-7 BBU Installation Assembly

Item Description

1 BBU LED.

2 Captive screws (6 per BBU). Use 7-9 in-lbs torque when tightening.

3BBU 2

4BBU 1

5BBU 0

6 Router door

5 4 3

1 2

300578
