B-5
Cisco 1240 Connected Grid Router Hardware Installation Guide
OL-26223-04
Appendix B Connector and Cable Specifications
Connector Specifications
Table B-8 Molex Part Specifications and Mating Connector Requirements
Part Molex Part Number Description
Included Module Power Connector Parts
Micro-Fit 3.0™ Receptacle
Housing
43025-0400 Power connector housing installed on the router
power harness for connection to an external,
non-Cisco module.
0.118 inch (3 mm) pitch
Dual row
4 circuits,
Halogen free
Micro-Fit 3.0™ Crimp
Terminal
43030-0003 Contacts installed on the router power harness for
connection to an external, non-Cisco module.
Female
Select gold (Au) plated phosphor bronze
contact
20-24 AWG
Reel
Cisco-Recommended Mating Parts
Pitch Micro-Fit 3.0™ Plug
Housing
43020-0401 Cisco recommends this or comparable part as
mating connector. Halogen free is a not a
requirement for the mating connector.
0.118 inch (3 mm) pitch
Dual row
Without panel mount ears
Halogen free
4 circuits
Micro-Fit 3.0™ Crimp
Terminal
43031-0003 Cisco recommends this or compartable part as
crimp terminal.
Male
Select gold (Au) plated tin/brass alloy contact
20-24 AWG
Reel
