3-15

Cisco 1240 Connected Grid Router Hardware Installation Guide

OL-26223-04

Chapter 3 Router Hardware Description

Hardware Features Detailed Description

Figure 3-11 Console Port Detail

Specifications

Specification Description

Connector type RJ-45

Transceiver RS-232

Cable type EIA RJ-45

Pinout See the “Connector and Cable Specifications”

appendix.

300543
