Chapter 3 Router Hardware Description
Hardware Features Detailed Description
Serial Port Cables
You can order a Cisco RJ-45 shielded serial-transition cable that has the appropriate connector for the
standard you specify. The documentation for the device should indicate the standard used for that device.
The router end of the shielded serial transition cable has a DB-25 connector, which connects to the
DB-25 port on a serial grid router WAN interface card. The other end of the serial transition cable is
available with a connector appropriate for the standard you specify. The synchronous serial port can be
configured as DTE or DCE, depending on the attached cable.
Specifications
Table 3-16 Serial Signal Transmission Speeds and Distances
Distance for
EIA/TIA-232
Rate (bps) Feet Meters
2400 200 60
4800 100 30
9600 50 15
19200 25 7.6
38400 12 3.7
56000 8.6 2.6
1544000 (T1) — —
Specification RS232 RS485
Connector type
RJ-45 RJ-45
Cable
.
See the “Serial Port Cables” section
on page 3-28
See the “Serial Port Cables” section
on page 3-28
Signaling
Single-ended Differential
Max. drivers
132
Max. receivers
1256
Operating mode
Full duplex Half duplex
Full duplex
Network topology
Point-to-point Multipoint
Note Multipoint is not enabled by
software.
Max. distance (standard)
15 m 1200 m
Max speed
(at 12 m/1200 m)
20 Kbps/1 Kbps 35 Mbms/100 Kbps
Pinouts
See Appendix B, “Connector and Cable Specifications”
