Cisco Catalyst 2950 User Manual

1-19
Catalyst 2950 and Catalyst 2955 Switch Software Configuration Guide
78-11380-12
Chapter 1 Overview
Network Configuration Examples
Figure 1-4 Network Hotel Configuration
Cisco 575
LRE CPE
PSTN
PBX
Floor 3
Floor 4
Rooms
and
users
Rooms
and
users
Cisco
LRE 48
POTS
splitters
Cisco 2600 router
Servers
Catalyst 2950ST-8 LRE and
2950ST-24 LRE switches
Catalyst 2950 or
Catalyst 3550 switch
Patch panel
89514
POTS telephones
Laptop
Cisco 575
LRE CPE
Laptop
POTS telephones
Required
microfilter
Required
microfilter
Required
microfilter
Cisco 585
LRE CPE
IP
phone
Laptop
Environmental
controls
Required
microfilter
Set-top
box
TV
IP
POTS telephone
POTS telephone
Cisco 585
LRE CPE
IP
phone
Laptop
Environmental
controls
Set-top
box
TV
IP

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
