Cisco CATALYST 2960

8-2
Catalyst 2960 and 2960-S Switches Software Configuration Guide, Release 15.0(1)SE
OL-26520-01
Chapter 8 Configuring SDM Templates
Understanding the SDM Templates
Note The lanbase-routing template is supported only on Catalyst 2960 and 2960-S switches running
Cisco IOS Release 12.2(55)SE or later andonly with the LAN base image.
• QoS—The QoS template maximizes system resources for quality of service (QoS) access control
entries (ACEs).
Table 8-1 Approximate Feature Resources Allowed on 2960-S Switch Templates
Resource Default
LAN base
routing
Unicast MAC addresses 8K 4 K
IPv4 IGMP groups 256 256
IPv4 unicast routes 256 .75 K
• Directly connected hosts .75 K
• Indirect routes 16
IPv6 multicast groups 0
Directly connected IPv6 addresses 0
Indirect IPv6 unicast routes 0
IPv4 policy-based routing aces 0
IPv4 MAC QoS ACEs 384 128
IPv4 MAC security ACEs 384 384
IPv6 policy-based routing aces 0
IPv6 QoS ACEs 0
IPv6 security ACEs 128 0
Table 8-2 Approximate Feature Resources Allowed on Catalyst 2960-C Fast Ethernet Switch
Te m p l a t e s
Resource Default QoS Dual
LAN base
routing
Unicast MAC addresses 8 K8 K8 K 4 K
IPv4 IGMP groups and multicast routes .25 K .25 K .25 K .25 K
IPv4 unicast routes 0 0 0 4.25 K
• Directly connected hosts 0 0 0 4 K
• Indirect routes 0 0 0 ,25 K
IPv6 multicast groups 0 0 .375 K 0
Directly connected IPv6 addresses 0 0 0 0
Indirect IPv6 unicast routes 0 0 0 0
IPv4 policy-based routing aces 0 0 0 0
IPv4 MAC QoS ACEs .125 K .375 K .125 K .125 K
