Chapter 10 Configuring IEEE 802.1x Port-Based Authentication
Understanding IEEE 802.1x Port-Based Authentication
You can configure open authentication with these scenarios:
• Single-host mode with open authentication–Only one user is allowed network access before and
after authentication.
• MDA mode with open authentication–Only one user in the voice domain and one user in the data
domain are allowed.
• Multiple-hosts mode with open authentication–Any host can access the network.
• Multiple-authentication mode with open authentication–Similar to MDA, except multiple hosts can
be authenticated.
For more information see the “Configuring the Host Mode” section on page 10-46.
Note If open authentication is configured, it takes precedence over other authentication controls. This means
that if you use the authentication open interface configuration command, the port will grant access to
the host irrespective of the authentication port-control interface configuration command.
Using Voice Aware 802.1x Security
Note To use voice aware IEEE 802.1x authentication, the switch must be running the LAN base image.
You use the voice aware 802.1x security feature to configure the switch to disable only the VLAN on
which a security violation occurs, whether it is a data or voice VLAN. When an attempt to authenticate
the data client caused a security violation in previous releases, the entire port shut down, resulting in a
complete loss of connectivity.
You can use this feature where a PC is connected to the IP phone. A security violation found on the data
VLAN shuts down only the data VLAN. The traffic on the voice VLAN continues without interruption.
For information on configuring voice aware 802.1x security, see the “Configuring Voice Aware 802.1x
Security” section on page 10-41.
802.1x Supplicant and Authenticator Switches with Network Edge Access
Topology (NEAT)
The Network Edge Access Topology (NEAT) feature extends identity to areas outside the wiring closet
(such as conference rooms). This allows any type of device to authenticate on the port.
• 802.1x switch supplicant: You can configure a switch to act as a supplicant to another switch by
using the 802.1x supplicant feature. This configuration is helpful in a scenario, where, for example,
a switch is outside a wiring closet and is connected to an upstream switch through a trunk port. A
switch configured with the 802.1x switch supplicant feature authenticates with the upstream switch
for secure connectivity.
Once the supplicant switch authenticates successfully the port mode changes from access to trunk.
• If the access VLAN is configured on the authenticator switch, it becomes the native VLAN for the
trunk port after successful authentication.
