39-15
Catalyst 2960 and 2960-S Switches Software Configuration Guide, Release 15.0(1)SE
OL-26520-01
Chapter 39 Troubleshooting
Using Layer 2 Traceroute
Note Though other protocol keywords are available with the ping command, they are not supported in this
release.
This example shows how to ping an IP host:
Switch# ping 172.20.52.3
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echoes to 172.20.52.3, timeout is 2 seconds:
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 1/2/4 ms
Switch#
Table 39-1 describes the possible ping character output.
To end a ping session, enter the escape sequence (Ctrl-^ X by default). Simultaneously press and release
the Ctrl, Shift, and 6 keys and then press the X key.
Using Layer 2 Traceroute
• Understanding Layer 2 Traceroute, page 39-15
• Usage Guidelines, page 39-16
• Displaying the Physical Path, page 39-17
Understanding Layer 2 Traceroute
The Layer 2 traceroute feature allows the switch to identify the physical path that a packet takes from a
source device to a destination device. Layer 2 traceroute supports only unicast source and destination
MAC addresses. It finds the path by using the MAC address tables of the switches in the path. When the
switch detects a device in the path that does not support Layer 2 traceroute, the switch continues to send
Layer 2 trace queries and lets them time out.
The switch can only identify the path from the source device to the destination device. It cannot identify
the path that a packet takes from source host to the source device or from the destination device to the
destination host.
Table 39-1 Ping Output Display Characters
Character Description
! Each exclamation point means receipt of a reply.
. Each period means the network server timed out while waiting for a reply.
U A destination unreachable error PDU was received.
C A congestion experienced packet was received.
I User interrupted test.
? Unknown packet type.
& Packet lifetime exceeded.
