Chapter 10 Configuring IEEE 802.1x Port-Based Authentication
Configuring 802.1x Authentication
Configuring a Guest VLAN
When you configure a guest VLAN, clients that are not 802.1x-capable are put into the guest VLAN
when the server does not receive a response to its EAP request/identity frame. Clients that
are 802.1x-capable but that fail authentication are not granted network access. The switch supports guest
VLANs in single-host or multiple-hosts mode.
Beginning in privileged EXEC mode, follow these steps to configure a guest VLAN. This procedure is
optional.
To disable and remove the guest VLAN, use the no authentication event no-response action authorize
vlan vlan-id interface configuration command. The port returns to the unauthorized state.
This example shows how to enable VLAN 2 as an 802.1x guest VLAN:
Switch(config)# interface gigabitethernet2/0/2
Switch(config-if)# authentication event no-response action authorize vlan 2
This example shows how to set 3 as the quiet time on the switch, to set 15 as the number of seconds that
the switch waits for a response to an EAP-request/identity frame from the client before re-sending the
request, and to enable VLAN 2 as an 802.1x guest VLAN when an 802.1x port is connected to a DHCP
client:
Switch(config-if)# authentication timer inactivity 3
Switch(config-if)# authentication timer reauthenticate 15
Switch(config-if)# authentication event no-response action authorize vlan 2
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the port to be configured, and enter interface configuration mode.
For the supported port types, see the “802.1x Authentication
Configuration Guidelines” section on page 10-38.
Step 3
switchport mode access Set the port to access mode.
Step 4
authentication port-control auto Enable 802.1x authentication on the port.
Step 5
authentication event no-response
action authorize vlan vlan-id
Specify an active VLAN as an 802.1x guest VLAN. The range is
1 to 4094.
You can configure any active VLAN except an RSPAN VLAN or a voice
VLAN as an 802.1x guest VLAN.
Step 6
end Return to privileged EXEC mode.
Step 7
show authentication interface
interface-id
Verify your entries.
Step 8
copy running-config startup-config (Optional) Save your entries in the configuration file.
