Sample Configurations
Configuring Motion Detection Area and Sensitivity
Cisco PVC2300 and WVC2300 Internet Video Cameras with Audio Administration Guide 116
9
Configuring Motion Detection Area and Sensitivity
NOTE Motion Detection cannot be configured using the Firefox browser. Internet Explorer
must be used to configure motion detection.
To set the motion detection area of the video image to be examined and adjust the
sensitivity of detection, follow these steps:
STEP 1 Click Setup in the toolbar.
STEP 2 Click Applications > Motion Detection. The Applications > Motion Detection
window displays.
STEP 3 Check the check box for either Full Screen or Setting Custom Area:
• Full Screen—Detects motion events within the full view of the screen.
• Setting Custom Area—Captures motion within defined areas of the video
screen. Multiple windows with varied threshold settings may be used.
- Window 2-4—Enable one or more of these options to detect motion in
specific areas of the video screen. Windows can be defined by simply
