Specifications
I/O Port Specifications
Cisco PVC2300 and WVC2300 Internet Video Cameras with Audio Administration Guide 135
C
I/O Port Specifications
The following diagram illustrates the I/O pin specifications for the PVC2300 and
WVC2300 cameras.
I/O Pin Specifications
Power
Consumption
10W
Environmental
Dimensions
W x H x D
4.72 in. x 2.99 in. x 1.81 in.
(120 mm x 76 mm x 46 mm)
Unit Weight 1.15 lb (0.52 kg)
Power External power adapter 12 VDC 1A 110~120VAC/60Hz switching
Certification FCC part 15C class B, CE, UL, EMC/EMI part 15B class B for US
Operating Temp. 32 to 122ºF (0 to 50ºC)
Storage Temp. -4 to 158ºF (-20 to 70ºC)
Operating
Humidity
10% - 80%, Non-condensing
Storage Humidity 0% - 90%, Non-condensing
Resource
Description
10 9 8 7 6 5 4 3 2 1
233952
