Configuring the PVC2300 and WVC2300 Cameras
Applications > Event
Cisco PVC2300 and WVC2300 Internet Video Cameras with Audio Administration Guide 92
8
Event Schedule
The Event Schedule displays the effective time frame and start/end times for
scheduled events. It contains a current profile of the event schedules. You can
delete an existing event schedule.
New Schedule
NOTE The camera can be configured for up to 10 events.
• Effective Time Frame—From the drop-down list, select the event time
frame. Available options are every day, weekdays, or a specific day of the
week.
• Start Time—Select the event start time in hours and minutes. Use the
24-hour time format.
• End Time—Select the event end time in hours and minutes. Use the
24-hour time format.
Click Add to add a new schedule or Clear to clear options and enter a new
schedule.
Trigger Event
A triggered event type is activated when a specific internal or external trigger
condition is met. These triggers are:
• A signal from a device connected to an input on the camera. For example, a
signal from a door switch.
• When movement is detected in a previously configured motion detection
window.
The configuration options for trigger event are:
• Enable—Check the box to perform all of the event(s) that are configured
and scheduled.
• Interval—Defaults to zero minutes before detecting the next event. Select
the desired interval before detecting the next event. (0 min = No Delay)
• Triggered by—Check the box to select a trigger option:
