Specifications
WVC2300 Specifications
Cisco PVC2300 and WVC2300 Internet Video Cameras with Audio Administration Guide 132
C
WVC2300 Specifications
Resource
Description
Model WVC2300
Standards IEEE802.11g, IEEE802.11b, IEEE802.3, IEEE802.3u, IEEE802.1p (QoS Priority),
IEEE802.1q (VLAN), 802.11e (Wireless QoS)
Protocols
Supported
TCP/IP, HTTP, DHCP, SMTP, FTP, NTP, DNS, UPnP, RTP, RTSP and DDNS
Ports Ethernet, Microphone IN, Speaker OUT, Power (12V, 1A), GPIO, 4-pin IRIS
port
Buttons Reset
Cabling Type UTP CAT 5
LEDs Power, Network
Camera Type Box
IO Ports RS-485 x 1 (2 pins) - Supports Pelco D Protocol commands:
• Input control x 2 (2 pins)
• Output control x 2 (2 pins)
Lens
Sensor 1/4-inch Progressive CCD Sensor
Illumination 0.4LUX@F1.4
Lens Type CS-mount lens, fixed focus. Adapter also included for lenses that require
more distance between sensor and lens.
Focal Length 500mm~Infinity (for included lens)
Field of View 60º (for included lens)
Video Resolution 640x48 (VGA), 320x240 (QVGA), 160x120 (QQVGA)
Frame Rate 1 to 30 fps (selectable)
Iris Provides DC-Iris control for CS-mount auto-iris lens when attached.
Setup/Config
Web UI Built in web UI for easy browser-based configuration (HTTP).
