Cisco SPA IP Phone Field Reference
System Tab
Cisco Small Business SPA 300 Series, SPA 500 Series, and WIP310 IP Phone Administration Guide 216
B
VLAN Settings
NOTE Not applicable to the WIP310.
Primary NTP Server IP address or name of primary NTP server.
Secondary NTP Server IP address or name of secondary NTP server.
Enable Bonjour (SPA 525G/
525G2 only)
Enable Bonjour networking that is used by Office
Manager and Cisco Configuration Assistant to discover
the Cisco IP phones. Choose yes to enable or no to
disable.
Parameter Description
Parameter Description
Enable VLAN Choose Ye s to enable VLAN. Choose no to disable.
Enable CDP
Enable CDP only if you are using a switch that has
Cisco Discovery Protocol. CDP is negotiation based
and determines which VLAN the IP phone resides in.
VLAN ID If you use a VLAN without CDP (VLAN enabled and
CDP disabled), enter a
VLAN ID for the IP phone. Note
that only voice packets are tagged with the VLAN ID.
Enable PC Port VLAN Tagging Enables VLAN and priority tagging on the phone data
port (802.1p/q). This feature facilities tagging of the
VLAN ID (802.1Q) and priority bits (802.1p) of the traffic
coming from the PC port of the IP phone.
Defaults to No. Choose Ye s to enable the tagging
algorithm.
PC Port VLAN Highest Priority 0-7 (default 0). The priority applied to all frames,
tagged and untagged. The phone modifies the frame
priority only if the incoming frame priority is higher than
this value.
PC Port VLAN ID 0-4095 (default 0). Value of the VLAN ID. The phone
tags all the untagged frames coming from the PC (it will
not tag frames with an existing tag).
