Cisco SPA 502G Administration Guide

Configuring Lines and Extensions
Configuring Lines
Cisco Small Business SPA 300 Series, SPA 500 Series, and WIP310 IP Phone Administration Guide 31
2
• news: RSS icon
• weather: thermometer icon
Configuring Line Key LED Patterns on the Cisco SPA 300
Series or Cisco SPA 500 Series IP Phone
You can customize the LED patterns for the line keys on the phone by entering
letters for the color or pattern in the LED pattern fields.
To configure Line Key LED patterns:
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the Phone tab.
STEP 4 Under Line Key LED Pattern, use the following letters to customize the fields
shown in the following table:
• “p” indicates “pattern”: the blinking pattern of the LED
• “c” indicates “color”: the color of the LED
• “r” indicates “red”: a red-colored LED
• “g” stands for “green”: a green-colored LED
Parameters Description
Idle LED Appears when the line is idle.
Defaults to blank (c=r).
Remote Undefined
LED
LED pattern during the Remote Undefined state, where the
shared call state is undefined (the station is still waiting for the
state information from the application server). Not applicable if
the call appearance is not shared. Leaving this entry blank
indicates the default value of c=r;p=d.
Local Seized LED Appears when this station seizes the call appearance to
prepare for a new outbound call.
Defaults to blank (c=r).
