Cisco SPA 502G Administration Guide

Cisco SPA IP Phone Field Reference
Ext Tab
Cisco Small Business SPA 300 Series, SPA 500 Series, and WIP310 IP Phone Administration Guide 272
B
Ext Tab
The Ext tabs vary by phone and depend on the number of extensions the phone
model supports.
This section describes the fields for the following Ext tab headings:
• General, page 252
• Share Line Appearance, page 273
• NAT Settings, page 274
• Network Settings, page 274
• SIP Settings, page 275
• Call Feature Settings, page 278
• Proxy and Registration, page 281
• Subscriber Information, page 283
• Audio Configuration, page 284
PSK1 through PSK6 To configure a speed dial script, enter the following
in the PSK field:
fnc=sd;ext=
extensionname @$PROXY;vid= outbound
extnum
;nme= name
where fnc is the function of the key (speed dial), ext
(
extensionname ) is the extension being dialed, vid is
the extension on the calling phone from which the
outbound call is sent, and
name is the name of the
speed dial being configured.
To configure an XML script, enter the following in the
PSK field:
fnc=xml;url=http://
scriptURL.xml ;nme= scriptname
where fnc is the function of the key (an XML script),
scriptURL.xml is the URL where the script is located,
and
scriptname is the name of the script.
Parameter Description
