TIC QUANTUM Electric System
10/04 12-17
2.2.2. Input assignment
Circuit Reed contact no. in display
Reed contacts:
Height alarm top On 1
Height alarm top Off 13
Height alarm bottom On 2 (up to serial no.)
Height alarm bottom Off 3 (up to serial no.)
Wagon full alarm (shredder drums) 4
Knife frame position
5
Close tailgate
6
Cross conveyor belt
7
Oil pressure switch:
150 bar tailgate open
8
2 bar control system On/Off
9
Shredder drum speed monitor
(switch on pto)
12
Knife frame open pushbutton
14
Knife frame close pushbutton
15
Switch closed = Number inverted
2.2.3 Output assignment
Circuit Solenoid valve no. in display
Pick-up On
1
Pick-up Off 2+14
Pick-up down
3
Pick-up up 4+14
Open knife frame 5+14
Close knife frame 6+14
Open tailgate 7+9+14
Lower tailgate
8
Lock tailgate 8+19+14
Raise articulated drawbar 10+14
Lower articulated drawbar 11+14
Floor conveyor proportional 25
Floor conveyor 2
nd
stage 13+25
Floor conveyor reverse slowly 12+14
Floor conveyor reverse quickly 13+14+12
Shredder drums On (engage pto) 15
Shredder drums Off 16+14
