Electric System QUANTUM TIC
12-18 10/04
2.2.4 Emergency operation
Operation Valve
Pick-up On 1
Pick-up Off 2+14
Pick-up down 3
Pick-up up 4+14
Open knife frame 5+14
Close knife frame 6+14
Open tailgate 7+9+14
Lower tailgate 8
Lock tailgate 8+19+14
Tailgate pressureless 9
Raise articulated drawbar 10+14
Lower articulated drawbar 11+14
Floor conveyor proportional 25
Floor conveyor 2
nd
stage (fast) 13+25
Floor conveyor reverse slowly 12+14
Floor conveyor reverse quickly 13+14+12
Hydraulic pressure 14
Shredder drums On 15
Shredder drums Off 16+14
Left cross conveyor belt 17+14+26
Right cross conveyor belt, fast 18+14+26
Steering axle 20+14
21 - 24
