TIC QUANTUM Operation
10/04 3-17
Unloading by means of
cross conveyor belt
Pull out the cross conveyor belt before unloading and lock it to the lower
back cover. Connect the hydraulic hoses to the hydraulic motor.
Switch on the pto for unloading with the cross conveyor belt and press
this key. The shredder drums start running and the floor conveyor is
switched on after a short delay.
To stop the unloading process, press this button again.
Any blockage of the shredder drums (the cut-out clutch of the universal
drive shaft is activated) by the material requires reversing the floor
conveyor.
Press these buttons simultaneously to reversing the floor conveyor.
Pressing this button increases the floor conveyor speed.
Pressing this button decreases the floor conveyor speed.
When pressing this key during the whole unloading process, the adjusted
floor conveyor speed is saved for further unloading processes.
This key enables changing the direction of rotation of the cross conveyor
belt.
From serial no.: …. with solenoid valve 62, the trailing axle can be
blocked with this key.
