TIC QUANTUM Operation
10/04 3-23
Unloading operation
Opening the tailgate
Press this key until the tailgate is open.
The green indicator light on the control panel will flash.
Discharge of the load
space
Press this key to discharge the load space.
The floor conveyor will travel to the rear as long as this key is pressed
once more.
Control the floor conveyor speed by means of the tractor’s speed.
Important! During the unloading operation the tailgate must be completely open and
the green indicator light must flash, otherwise the floor conveyor cannot
be operated.
Closing the tailgate
Press this key until the red indicator light starts flashing.
The tailgate is lowered due to its weight (i.e. without hydraulic pressure)
as long as this key is pressed.
Release this key when the red indicator light on the control panel starts
flashing. Hydraulic pressure builds up and the tailgate is locked. The red
LED (100%) is no longer illuminated.
