Technical Data QUANTUM TIC
1-4 10/04
QUANTUM
3800 K
QUANTUM
3800 P
Length (L) mm 9,250 9,250
Width (B) mm 2,550 2,550
Height (H) – dry forage assembly folded up mm 3,410 3,600
Height (S) – dry forage assembly folded down mm 2,600 3,050
Track width mm 1,850 1,850
Pick-up width mm 1,800 1,800
Platform height mm 1,180 1,180
Loading capacity (acc. to DIN 11741) m
3
31.8 33.2
Kerb weight kg 5,550 5,650
Permissible total weight (compressed air) 11,000 11,000
Number of cutting knives 33 33
Shortest theoretical length of cut mm 45 45
Number of pick-up tines per tine bar 26 26
Tine spacing mm 61 61
PTO speed min
-1
1.000 1.000
Tyres
- compressed air up to 40 km/h
- compressed air up to 60 km/h
500/50-17 10 PR
555/45-17 10 PR
500/50-17 10 PR
555/45-17 10 PR
Tyre pressure - with tyres 500/50-17
555/45-17
19.0/45-17
bar
bar
bar
3.5
3.0
3.0
3.5
3.0
3.0
Tightening torque of wheel nuts - wagon
wheels M18x1.5
M20x1.5
Nm
270
300
270
300
Sound pressure level dB(A) 70 70
