9.2.12 BA ROLLANT 240 - 250 - 254 - 255 - 000 299 119 5
Operation
Swashing the knives out
1. Actuate push button (4). The light (10) confirms
the selection.
2. Lower the pick-up completely with the tractor
hydraulics. The knives are thereby swashed out
via the hydraulic cylinders. The pick-up can then
be raised again completely.
Note!
The knives first remain in swashed-in position.
The following baling material forces the knives
back.
(Fig. 14)
Adjusting the volume of the audible warning signal
Procedure:
1. Pull end cap (E) off the control box.
2. Use a screwdriver to turn the screw of
potentiometer (P).
Increasing the volume: turn clockwise. Reducing
the volume: turn anti-clockwise.
(Fig. 15, 16)
Blockages on the baler
See sections 9.2.1 - 9.2.3
15
16
