Claas ROLLANT 250 User Manual

000 299 119 5 - BA ROLLANT 240 - 250 - 254 - 255 8.1.5
Setting up the baler
– Loosen screws (F).
– Adjust the height (arrow) of plate (B) as
appropriate to the swath proportions.
– Tighten up screws (F) again after the adjustment.
– Pull the chain (D) off the hook (E).
– Tighten up the spring (C) in the hook (E) again.
– If necessary set up plate (L) (to straw position or
the silage/hay position).
– Follow the instructions on adjustments for the
other side of the roller crop guard.
Note!
The roller crop guard must have the same
settings on both sides.
(Fig. 10, 11)
Adjusting the roller crop guard where there are
problems with the bale material feed
If the bale material feed is not set up exactly, the
position of the plate (G) can be changed with the help
of the longitudinal slots (K).
– Loosen the screws.
– Adjust position of the plate (G) using the
longitudinal slots (K).
– Retighten the screws.
– Remove the crop guard (H) (if desired).
Attention!
Damage to side flaps
☞ Never open or close the side flap when
the roller crop guard and the pick-up are
set to a higher level.
(Fig. 11, 12)
Driving the baler with the roller crop guard
Before transport, pull off the springs on the roller crop
guard.
F
B
H
L
11
K
G
12
