Clark GEX20 - Page 133

Group 19, Motor Controls
SM 765, Sep ’06 Control Programming • 19-2-3
Gex Handset
Master Control Configuration
Main Menu Set Model Connected to 3 (Master), 4 (Slave), 5 (Pump)
Parameter Acceleration Delay 0-9 Set Options Hour Meter Running / Key On
Change Release Braking 0-9 Battery Check On/Off
Inverse Braking 0-9 Hydraulic Key On On/Off
Pedal Braking 0-9 Stop On Ramp On/Off
Speed Limit Braking 0-9 Aux Input #1 Exclusive Hyd / Option #1 / Option #2
Brake Cutback 0-9 Pedal Braking Analog / Digital / None
Max Speed Forward Hz Steer Table Option #1 / Option #2
Max Speed Reverse Hz
Curve Cutback %
Frequency Creep Hz Adjustments Set Pot Brake Minimum
Maximum Current 0-9 Set Pot Brake Max
Auxilary Time Sec Set Battery Type 80V
Adjust Battery
Max Steer Right
Max Steer Left
Set Steer 0-Position
Set Steer Right
Set Steer Left
Throttle 0 Zone
Throttle Y Zone
Throttle X Zone
Adjustment #04
Adjustment #01 (Display) 0-9
Adjustment #02 (Shut Down) 0-9
Main Contactor Voltage
Aux Output Voltage
Maintenance Done On/Off
Maintenance None / Opt #1 / Opt #2
1 X 10,000 Hours 0-6
1 X 1,000 Hours 0-9
1 X 100 Hours 0-9
1 X 10 Hours 0-9
1 X 100 Hours 0-9
HEADING
DISPLAY
KEYBOARD
DA2M2BGCPE CK 0.13
80V 280A 00000
DISPLAY
KEYBOARD
Enter
Enter
Enter
Enter
Roll
Up
Roll
Up
”C
... V
... V
... V
... V
... V
... V
... V
... V
...%
...%
...%
...”
...”
DA2M2BGCPE CK 0.13
80V 280A 00000
Tester
Save
Parameter
Restore
Parameter
Alarms
Program
VACC VACC Settings Min/Max
Motor Data
Not Available
Roll
Up
Roll
Up
Roll
Up
Roll
Up
Roll
Up
Enter
Enter
Enter
Code, h, N”, ”C
Seat Micro Delay Sec
Acc Smooth Sec
Inv Smooth Sec
Stop Smooth Hz
Idle Time Min
Motor Voltage %
Frequency Hz
Encoder Hz
Slip Value Hz
Current RMS A
Temperature
Temperature #1
Temperature #2
Accelerator V
Steer Angle
Brake Pedal Pot %
Inner Wheel Cutback %
Seat Switch On/Off
Forward Switch V
Reverse Switch V
Enable Switch On/Off
Brake Switch On/Off
Cutback Switch On/Off
Exclusive Hydraulics On/Off
Hand Brake On/Off
Voltage Booster %
Battery Voltage V
Battery Charge %
Enter
”C
”C
”C
...”
