Group 19, Motor Controls
19-2-6 • Control Programming SM 765, Sep ’06
13. ADJUSTMENT #04:
(Do Not Change)
Determines the motor temperature level at which the "Motor Temperature" fault is
signaled. The default temperature is 130° C. Icon on dash will illuminate at this
temperature.
14. MOTOR SHUTDOWN:
(Do Not Change)
This parameter determines the motor temperature level at which the "Motor Shut-
down" fault is signaled. The default temperature is 145° C.
15. ADJUSTMENT #01 Adjust the upper level of the battery discharge table.
16. ADJUSTMENT #02 Adjust the lower level of the battery discharge table.
17. ADJUSTMENT #3 Adjust percentage of battery change it take to reset battery state of charge on dash
display.
18. MAIN CONT VOLTAGE: Adjusts the Line contactor coil voltage (PWM output C26).
19. AUX OUTPUT VOLTAGE: Adjusts the Electric brake coil voltage (PWM output C28).(Not Used)
20. MAINTENANCE DONE: OFF is the default Setting. When a maintenance warning occurs, the operator can
cancel the warning setting this parameter ON. When the truck is turned on again
this parameter becomes OFF.
21. MAINTENANCE:
-NONE: When truck reaches maintenance time, if this parameter is set as NONE, the con-
troller gives a maintenance warning but does not reduce performance.
OPTION #1: When truck reaches maintenance time, if this parameter is set as OPTION #1, the
controller gives a maintenance warning and reduces truck performance
OPTION # 2: When truck reaches maintenance time, if this parameter is set as OPTION #2, the
controller gives a maintenance warning and stops the truck.
22. MAINTENANCE TIME: Sets the number running truck hours before setting the maintenance fault. This is a
count down timer, it must be reset after each PM.
23. 1x 10, 000 HOURS: Sets the ten thousands units of the hour meter displayed on the dash display. This
will not change the hour meter of the controller.
24. 1x 1, 000 HOURS: Sets the thousands units of the hour meter displayed on the dash display. This will
not change the hour meter of the controller.
25. 1x 100 HOURS: Sets the hundreds units of the hour meter displayed on the dash display. This will
not change the hour meter of the controller.
26. 1x 10 HOURS: Sets the ten units of the hour meter displayed on the dash display. This will not
change the hour meter of the controller.
27. 1x 1 HOURS: Sets the units of the hour meter displayed on the dash display. This will not change
the hour meter of the controller.
