19, Motor Controls
SM 765, Nov ’06 GEX Factory Control Settings • 19-4-1
Refer to Section 2 for Handset Programming Instructions
Name Scaled Value
Master (DUALAC2)
PARAMETER CHANGE Turtle Mode Economic Mode Normal Mode Power Mode
ACCELER. DELAY LEVEL = 6 LEVEL = 6 LEVEL = 5 LEVEL = 4
RELEASE BRAKING LEVEL = 3 LEVEL = 2 LEVEL = 2 LEVEL = 1
INVERS. BRAKING LEVEL = 4 LEVEL = 5 LEVEL = 6 LEVEL = 6
PEDAL BRAKING LEVEL = 7 LEVEL = 7 LEVEL = 7 LEVEL = 7
SPEED LIMIT BRK. LEVEL = 0 LEVEL = 0 LEVEL = 0 LEVEL = 0
BRAKE CUTBACK LEVEL = 5 LEVEL = 5 LEVEL = 5 LEVEL = 5
CURVE BRAKING LEVEL = 5 LEVEL = 5 LEVEL = 5 LEVEL = 5
MAX SPEED FORW
(Do Not adjust to a higher HZ)
47 Hz 79 Hz 119 Hz 143 Hz
MAX SPEED BACK
(Do Not adjust to a higher HZ)
47 Hz 79 Hz 119 Hz 143 Hz
CUTBACK SPEED 1 80% 90% 100% 100%
CURVE CUTBACK 40% 40% 40% 40%
CURVE CUTBACK 1 100% 100% 100% 100%
FREQUENCY CREEP 0.30 Hz 0.30 Hz 0.30 Hz 0.30 Hz
MAXIMUM CURRENT LEVEL = 9 LEVEL = 9 LEVEL = 9 LEVEL = 9
AUXILIARY TIME 4.5 4.5 4.5 4.5
SEAT MICRO DELAY 3.5 3.5 3.5 3.5
ACC. SMOOTH 2.5 2.5 2.0 1.5
INV. SMOOTH 2.0 2.5 2.0 1.5
STOP SMOOTH 20Hz 15Hz 10Hz 10Hz
IDLE TIME 15 15 15 15
SET OPTION
HOUR COUNTER RUNNING RUNNING RUNNING RUNNING
BATTERY CHECK ON ON ON ON
HYDRO KEY ON OFF OFF OFF OFF
STOP ON RAMP OFF OFF OFF OFF
AUX INPUT #1 OPTION #1 OPTION #1 OPTION #1 OPTION #1
PEDAL BRAKING DIGITAL DIGITAL DIGITAL DIGITAL
SET TEMPERATURE ANALOG ANALOG ANALOG ANALOG
STEER TABLE OPTION #2 OPTION #2 OPTION #2 OPTION #2
MODE SELECTION
LEVEL = 3 LEVEL = 0 LEVEL = 1 LEVEL = 2
Section 4
GEX Factory Control Settings
Parameters in White are customer preference adjustable.
Parameters in Orange are factory preset and not adjustable.
