Group 19, Motor Controls
SM 765, Nov ’06 GEX Factory Control Settings • 19-4-3
* See AUX Hydraulic Settings in Section 3
PARAMETER CHANGE Turtle Mode Economic Mode Normal Mode Power Mode
ACCELER. DELAY LEVEL = 0 LEVEL = 0 LEVEL = 0 LEVEL = 0
DECELER. DELAY LEVEL = 0 LEVEL = 0 LEVEL = 0 LEVEL = 0
ACCELER. DELAY TILT
LEVEL = 0 LEVEL = 0 LEVEL = 0 LEVEL = 0
DECELER. DELAY TILT LEVEL = 0 LEVEL = 0 LEVEL = 0 LEVEL = 0
ACCELER. DELAY AUX1
LEVEL = 0 LEVEL = 0 LEVEL = 0 LEVEL = 0
DECELER. DELAY AUX1
LEVEL = 0 LEVEL = 0 LEVEL = 0 LEVEL = 0
ACCELER. DELAY AUX2 LEVEL = 0 LEVEL = 0 LEVEL = 0 LEVEL = 0
DECELER. DELAY AUX2 LEVEL = 0 LEVEL = 0 LEVEL = 0 LEVEL = 0
MAX SPEED UP 60 Hz 75 Hz 100 Hz 100 Hz
MIN SPEED UP 16.50 Hz 16.50 Hz 16.50 Hz 16.50 Hz
CUTBACK SPEED 100% 100% 100% 100%
1ST SPEED FINE* 40 Hz 40 Hz 40 Hz 40 Hz
2ND SPEED FINE* 25 Hz (S/Shift) 25 Hz (S/Shift) 25 Hz (S/Shift) 25 Hz (S/Shift)
3RD SPEED FINE* 50 Hz 50 Hz 50 Hz 50 Hz
4TH SPEED FINE* 50 Hz 50 Hz 50 Hz 50 Hz
HYD SPEED FINE 21 Hz 21 Hz 21 Hz 21 Hz
IDLE SPEED 12 Hz 12 Hz 12 Hz 12 Hz
IDLE TIME LEVEL = 5 LEVEL = 5 LEVEL = 5 LEVEL = 5
MAXIMUM CURRENT LEVEL = 9 LEVEL = 9 LEVEL = 9 LEVEL = 9
AUXILIARY TIME 2 2 2 2
SET OPTION
HOUR COUNTER RUNNING RUNNING RUNNING RUNNING
SET TEMPERATURE ANALOG ANALOG ANALOG ANALOG
THERM PROTECTION OFF OFF OFF OFF
HOUR METER TRUCK ON ON ON ON
PRESSURE FUNCT. OFF OFF OFF OFF
DIGITAL LEFT OFF OFF OFF OFF
SET MODEL
CONNECTED TO 5 (PUMP) 5 (PUMP) 5 (PUMP) 5 (PUMP)
ADJUSTMENTS
SET BATTERY TYPE 80V 80V 80V 80V
ADJUST BATTERY
THROTTLE 0 ZONE 5% 5% 5% 5%
THROTTLE X POINT 63% 63% 63% 63%
THROTTLE Y POINT 36% 36% 36% 36%
ADJUSTMENT #04 130 °C 130 °C 130 °C 130 °C
MOTOR SHUTDOWN 145 °C 145 °C 145 °C 145 °C
IMAX PROTECTION 100% 100% 100% 100%
ADJUSTMENT #03 55 °C 55 °C 55 °C 55 °C
