Group 26, Steer Axle
SM 765, Dec ’06 Steering Axle Overhaul • 26-4-1
Preparation for Steer Axle Disassemble and Overhaul .... 2
Steer Axle Disassembly ....................................................... 2
Parts Inspection ................................................................... 3
Steer Axle Reassembly ........................................................ 3
IMP
RTANT
Before removing any component for overhaul, make sure the correct repair parts, seals, and gasket sets
are available.
CAUTION
!
SAFE PARKING. Before working on truck:
1. Park truck on a hard, level, and solid surface, such as a concrete floor with no gaps
or breaks.
2. Put upright in vertical position and fully lower the forks or attachment.
3. Put all controls in neutral. Turn key switch OFF and remove key.
4. Apply the parking brake and block the wheels.
