Eclipse | Upgrade Guide
Page 21
Order
System component
Upgrade procedure(s)
Notes
1
E-QUE card
IVC-32 card
LMC-64 card
9.1 Identifying MK1 and MK2 E-QUE cards
9.2 Upgrading the E-QUE card (MK1)
9.3 Upgrading the E-QUE card (MK2)
The procedures used to upgrade
E-QUE cards to Eclipse HX v9.1
can also be used to upgrade IVC-
32 and LMC-64 cards.
No PROM upgrade is required
2
E-MADI64 card
11.3 Upgrading the E-MADI64 application, DSP and FPGA code
using EHX
11.4 Upgrading the E-MADI64 FPGA using the Xilinx tool set
No DSP upgrade required.
(Note – if the E-MADI64 card
is upgraded before the CPU
Card then there is no E-MADI
card LED activity during the
upgrade. See E-MADI64
section for important upgrade
information).
3
E-FIB card
No upgrade required.
4
V-
Serie
s
panel
s
Uboot
14.3 Manually upgrading V-Series Panels
Kernel
Root file
system
App code
14.3 Manually upgrading V-Series Panels
Display module
14.1 Upgrading panels using EHX
