For this (first) device, select the U53 CPLD code. The U53 CPLD code for the CPU
card is available from the Drivers USB:
• Drivers USB > ECLIPSE DRIVERS > Omega-Median-Delta > xxxxxx
- Config Card U53 CPLD code.
Note: xxxxxx represents the part number.
The folder contains a CPLD code file (*.jed) and a Read Me file (*.txt), which
contains version information.
10) Right click the first device (U53) and select Programming.
The upgrade starts, and takes approximately 2 minutes to complete. When the
upgrade is complete, the Program Succeeded message is displayed in the
main window.
11) Power down the CPU card.
5.10 Upgrading the CPU card U1 CPLD code with Xilinx
tools
Use the following procedure to upgrade the U1 CPLD code for the CPU card.
To upgrade the CPU U1 CPLD code with Xilinx tools:
1) Check that you have the latest version of Xilinx tools installed.
Tip: Upgrading the CPU card(s) CPLD code using Xilinx tools requires specialized
equipment. For more information about installing Xilinx programming tools, see
Appendix J:Xilinx tools.
2) Connect the USB connector of the download cable (Platform cable USB DLC9G)
to the USB port of the PC.
3) Connect the 14way IDC header to CON11.
4) Power up the CPU card and start the iMPACT programming tool.
5) In Load Project, select Cancel.
6) Hold the CPU card in reset by inserting a suitable tool into the Reset pin at the
top of the card. You must press and hold the reset pin during the whole upgrade
process.
7) In Flows, double click Boundary Scan. Right click the main window and select
Initialise Chain / Ctrl+ I:
