15 Upgrading the TEL-14 module
This chapter describes how to upgrade the TEL-14 module, including how to:
• Replace the TEL-14 processor.
• Re-fit TEL-14 modules.
• Update TEL-14 firmware.
Note:
This guide is laid out in the order in which you must upgrade your Eclipse HX software
and hardware devices. For a quick reference to upgrading your system, see
3Quick reference: Upgrading to Eclipse HX.
15.1 Upgrading the TEL-14 hardware
To upgrade the TEL-14 hardware, you require the following equipment:
• The old Tel-14 card
• The replacement TEL-14 processor module.
• Flash Magic Software. Third party software is available from either of the
Eclipse HX 9.0 upgrade media:
Software USB > SOFTWARE - EHX.xxx > 3rd_Party_Software >
FlashMagic
Drivers USB > ECLIPSE DRIVERS > 3rd_Party_Software >
FlashMagic
Tip: For more information about installing Flash Magic, see
Appendix H: Flash Magic.
• TEL-14 application software. The TEL-14 application software (*.HEX
format file) is available from the software USB:
Drivers USB > ECLIPSE DRIVERS > Other_Software >xxxxxx-TEL-
14 Application
Where xxxxxx represents the product number.
To upgrade the TEL-14 hardware:
1. Remove the four screws securing the front panel and remove the front panel.
2. Remove the three screws securing the PCB without the backplane connector and
open the two cards up. It is not necessary to disconnect the two cards.
