11 Upgrading E-MADI64 cards
This chapter describes how to upgrade MK1 E-MADI64 cards. The following E-MADI64
code can be upgraded:
• The boot code file (*.mot), which is upgraded using the Renesas Flash Development Toolkit
3.4 Basic (FDT).
• The application code and DSP code files (*.fwc), which are upgraded using EHX.
• The FPGA code, which is upgraded using either EHX or Xilinx iMPACT programming
software.
Note:
This guide is laid out in the order in which you must upgrade your Eclipse HX software
and hardware devices. For a quick reference to upgrading your system, see
3 Quick reference: Upgrading to Eclipse HX.
11.1 Identifying MK1 and MK2 E-MADI64 cards
Note: this chapter only describes how to update MK1 E-MADI64 cards.
To identify the E-MADI64 card as a MK1 or a MK2 card, run a firmware report in EHX. To
use the Firmware report tool:
a. Go to EHX> System> Layout .
b. Right click the matrix icon.
c. Select Firmware > Firmware report.
You can also identify MK 1 and MK 2 cards visually.
