Clear-Com FreeSpeak II FSII-TCVR-24 - Freespeak II with an FSII IP Transceiver

User Guide| FreeSpeak II for Eclipse HX
Radio Frequency
(RF) Band
Minimum number. of
transceivers in one RF cell
Maximum number of beltpacks
supported in one RF cell
4 16 - 20
2.4 GHz 1 3 - 4
2 4 - 6
3 7 - 9
4 10 - 12
2.3 FreeSpeak II with an FSII IP Transceiver
Using the FreeSpeak II system with an IP transceiver increases the capacity and range of your
system.
l The IP transceiver is used with the E-IPA-HX card (Eclipse 10.0 and above software).
l E-IPA-HX card operates on a license basis. You can buy a card with a 16, 32, 48 or 64 port
license.
The E-IPA card enables up to 64 FS II connections (according to license) which may be made up
of any combination of:
l FS II IP Transceivers (up to 64)
l FS II beltpacks (up to 64)
Radio Frequency
(RF) Band
Minimum number. of
transceivers in one RF cell
Maximum number of beltpacks
supported in one RF cell
1.9 GHz BV32
codec
1 8 - 10
2 16 - 20
3 24 - 30
4 32 - 40
2.4 GHz Not supported Not supported
Note: The IP Transceiver supports up to 10 beltpacks, but to enable effective roaming Clear-Com
recommends eight beltpacks per transceiver.
Page 10
