User Guide| FreeSpeak II for Eclipse HX
8.4 Splitter (FSII-SPL) front panel
See also:
Splitter (FSII-SPL) rear connectors on page 90
Using the FreeSpeak II Base splitter (FSII-SPL) on page 88
8.5 Using a transceiver with a fiber connection
You may wish to connect a FreeSpeak II Base to a splitter (FSII-SPL) using Fiber. In this case,
you need to install Fiber modules to the Base and the splitter.
l Modules are available for single mode Fiber cable (HLI-SMFO) and multi-mode Fiber cable
(HLI-MMFO)
l Modules are supplied as a pair, one for the Base Station and one for the splitter.
l Modules can be hot patched, no need to power off devices.
Page 91
