User Guide| FreeSpeak II for Eclipse HX
Key to transceivers
Feature Description
USB connector. Used to upgrade the firmware in the FS II-TA.
Matrix connector. This RJ-45/etherCON connector is used to connect the bi-
directional signal from the matrix, directly or via the splitter. Up to 800 metres (2625
feet) of 4-pair 24AWG shielded Ethernet cable (CAT5/5e/6) can be used for this
connection between matrix and transceiver. If 26AWG cable is used the maximum
distance is 400 metres (1312 feet).
DC in power connector. This connector is used to locally power the transceiver with
the supplied universal power supply. Use of local power is required when the
transceiver is located more than 100 metres (328 feet) from the matrix or the splitter,
and is recommended even when the transceiver is closer whenever it is available and
convenient.
Data signal/Power LEDs. This amber LED indicates that a connection has been
established between the matrix and the transceiver, and that it is actively creating a
coverage zone within which the beltpacks can operate.
A flashing amber LED indicates that a data connection has been established with the
matrix. A solid amber light shows that there is a DECT synchronization lock between
the devices. A solid light is required for normal operation of the system.
Power LED. This LED indicates that the transceiver is receiving power, either from its
local power supply or from the connected CAT-5 cable (distances up to 100 metres, or
328 feet, from the matrix or the splitter) being powered via the FS II Matrix.
This light is green for FSII 1.9 GHz devices and blue for FSII 2.4 GHz devices.
Mode button. The mode button is currently not in use.
7.3 Cabling the FS II transceivers
The transceivers can be cabled in two modes:
l Transceiver mode – connect directly to transceiver (up to 8 transceivers per E-Que card)
l Splitter mode – connect to transceiver via splitter (up to 2 splitters; 10 transceivers per card).
Note: A matrix system can support up to four E-Que-HX cards (six for an Omega matrix). This makes the
maximum number of transceivers per system up to 40.
Page 72
