User Guide| FreeSpeak II for Eclipse HX
l Site Survey
Note: The menus that appear depend on the menu access level. See Setting full menu access on
page 43.
To select a submenu turn either of the two rotary dials clockwise. This will scroll down the
submenu options. If you turn the rotary dials counter-clockwise, you will scroll upwards.
To select a submenu, press the Menu Select key (D).
To return to the previous screen, press the Menu Cancel key (C). You can also return to the
previous screen by pressing the Menu key.
Each menu screen on the beltpack has the following structure:
l Header - this displays the menu title
l Body - this displays a scrollable list of menu items
l Footer - this displays the current value of the current menu selection
To exit the beltpack menus, press the Menu key.
5.2 Configuring the beltpack volume settings
You can configure the following:
l The volume on each of the four channels
l The beltpack master volume
l The volume of the line-in feed.
5.2.1 Configuring the beltpack channel volumes and master volume
Each of the four beltpack channel volume levels is configurable separately.
Note: You can only change volume levels on keys that have been configured.
To configure a channel volume:
1. To enter the beltpack menu, press and hold the Menu key.
2. Turn either rotary control clockwise to highlight Vol Level Ctrl, and press the Menu Select
key (D). The Volume Level Control screen appears:
Page 36
