User Guide| FreeSpeak II for Eclipse HX
Beltpack display icons and indicators
Name Icon Description
Key label
A descriptive name for the channel. The maximum length is
10 characters.
Role name A descriptive name for the beltpack role.
Channel listen
volume level
The volume of the channel audio.
Signal strength
Bars that indicate the strength of the signal from the Main
Station.
Battery level Indicates the battery time remaining.
4.2.3 Beltpack headset tones/alerts
Note: To change call signal, low battery or out-of-range alerts go to Menu (press and hold) -> Settings ->
Alarm options on your beltpack. Choose from Vibrate & audio/Vibrate only/Audio only/Off.
Beltpack headset tones/alerts
Event Tone
Call signal
Mid to high beep, as long as call is active
Mid on 200ms, mid off 0ms, high on 200ms, high off 400ms. Repeat if key held.
Low battery
High beep, long then short.
High, on 400ms, off 100ms, on 100ms.
Repeats intermittently.
Out-of-range
High beep, long then short (as above).
Repeats as long as beltpack is out of range.
Page 25
